Cov xim sib txuam tshuaj pleev xim, siv primer, xim xim, thiab cov xim pleev xim rau cov xim pleev xim rau hauv cov kab ke, ua ke nrog cov xim sib xyaw ua ke, ua kom pom tseeb ntawm qhov agility thiab elegance ntawm cov khoom. Cov xim yog ntxiv nrog UV resistant Cheebtsam, uas yuav tsis muaj hnub nyoog los yog ploj mus txawm tias tom qab ntev raug tshav ntuj.
Lub tsheb teeb / grille, siv kev sib xyaw ntawm lub tsheb style headlights, nruab nrog cov kab teeb ci siab thiab qis, tig teeb pom kev zoo, txhawm rau txhim kho tsheb kev nyab xeeb thiab kev tsav tsheb. Lub lens hom teeb lub teeb sib xyaw ua ke lub teeb fluorescent thiab lub teeb ci siab, nrog lub siab pob tshab thiab lub teeb pom kev ntev. Lub teeb nraub qaum tuaj yeem muab cov cim qhia meej thaum nres, ua rau kev tsav tsheb nyab xeeb hauv qhov chaw tsis muaj teeb pom kev zoo. Laser carved mesh, nrog siab -kawg zoo thiab uniqueness.
Parameter
|
Qhov siab tshaj plaws |
Tom ntej: 22km / h; Rov qab: 9km / h |
|
Qib Muaj peev xwm |
40% (≈21.8 degree) |
|
Tig Radius |
Tsawg dua los yog sib npaug li 3m |
|
Dimension |
2800 × 1250 × 1800 (mm) |
|
Wheelbase |
1650 hli |
|
Khiav |
Pem hauv ntej log: 870mm; rear log: 985mm |
|
Tay Load |
360kg ua |
|
Ncej |
Lub zog muaj zog aluminium / carbon steel ib leeg thav duab |
|
Kev ncua |
Pem Hauv Ntej Suspension: Macpherson ywj siab ncua; Tsheb Suspension: Nplooj caij nplooj ntoos hlav thiab hydraulic shock absorbers |
|
Nres |
Plaub - log hydraulic nres system + Hluav taws xob nres nres (EM Nres) |
|
Roj teeb |
Cov roj teeb tsis muaj kev kho mob / Lithium hlau phosphate |
|
Tsav Tsav |
AC lub cev muaj zog 4KW |
|
Tus tswj |
48V AC maub los |
MCPHERSON TSIS TXAUS SIAB TSHAJ
Raws li nyob rau hauv koj lub tsheb ncua kev kawm ntawv, peb siv kauv damping springs kom tshem tawm qhov tsis zoo ntawm kev co thiab shocks. Peb qhov kev ncua yuav tsim lub cushion ntxiv rau koj lub rooj zaum.
TRACTION MOTOR
Lub cev muaj zog muaj ib qho kev ua haujlwm zoo tshaj plaws rau kev tswj xyuas ceev, thiab pab kom GREENMAN CAR sib npaug sib luag nyob rau hauv toj siab lossis tiaj tus.
BEEFED UP TRANSAXLE
Lub siab sib xyaw ua ke- tuag-casting aluminium gearbox vaj tse yog kaw nruj nreem; Fais fab kis tau los ntawm mesh thiab involute hniav bevel gears, uas ua kom muaj zog tso zis torque, qis suab nrov thiab ntau zoo dua efficiency
CURTIS CONTROLER
Peb tau teev Curtis qauv uas tau ntim nrog Kev Tiv Thaiv Kev Tiv Thaiv thiab Anti Skipping regenerating braking los muab cov neeg siv khoom muaj kev nyab xeeb ntau dua kev caij tsheb npav
